| Specification | Details |
|---|---|
| Technical | |
| Ambient Air Temperature: | |
| Operation | -25 ... +70 °C |
| Storage | -40 ... +85 °C |
| Color: | Red |
| Actuator Type: | Pilot light head |
| Illumination: | Illuminated |
| Lamp Type: | 110-13 V AC, integrated LED |
| Enclosure Type NEMA: | Type1, Type12, Type13, Type3R, Type4, Type4X |
| Pollution Degree: | 3 |
| Rated Frequency (f): | Supply Circuit 50 / 60 Hz |
| Rated Operational Voltage: | 110 ... 130 V AC |
| Supply Circuit | 110 ... 130 V AC |
| Connecting Capacity: | Flexible with Ferrule 1 x 0.75...2.5 mm², Flexible with Ferrule 2 x 0.75...2.5 mm², Flexible with Insulated Ferrule 1 x 0.75...2.5 mm², Flexible with Insulated Ferrule 2 x 0.75...2.5 mm², Flexible 1 x 0.75 ... 2.5 mm², Flexible 2 x 0.75 ... 2.5 mm², Solid 1 x 0.75...2.5 mm², Solid 2 x 0.75...2.5 mm² |
| Connection Type: | Screw Clamp |
| Terminal Type: | Screw Terminals |
| Tightening Torque: | 0.9 N·m |
| Wire Stripping Length: | 8 mm |
